PTFE Thin Film

Name: China PTFE Thin Film Manufacturers Suppliers - Customized PTFE Thin Film Made in China - Aochen International
Brand: AOCHEN
SKU: 280592911

Product code: ACI25001-4
Product Description: PTFE Thin Film
PTFE film is used PTFE resin by moulding and sintering into blank, made by turning into the film is not directed film, not directed film made by the rolling direction and semi-directed film. It has good electrical PTFE-specific properties, non-sticky and low friction coefficient and other characteristies. PTFE film is for the use of high temperature, corrosive liquid used in motor as a generator of the insulation material, coil insulation material, a variety of machines into the mouth of the insulation material, etc..

Send Inquiry

Description

Products DescriptionTel：+86-19803278181

Product Code: ACI25001-4

Product Description: PTFE Thin Film

Function:

▪ Unaffected by almost all chemicals

▪ Continuous use at high temperatures

▪ Slippery non-stick surface

▪ Outstanding dielectric properties

▪ Wear-resistant, Impact-resistant, Heat-resistant, Corrosion-resistant, Insulating, Cold-resistant

Color: Natural white, Black, other

Products SpecificationsTel：+86-19803278181

SPECIFICATION

Width: 20~300mm (conventional width 100mm, customizable)

Thickness: 0.03, 0.04, 0.05, 0.06, 0.08, 0.1, 0.2, 0.3mm

PTFE PERFORMANCE PARAMETER
		METRIC
PROJECT NAME	UNIT	DIRECTIONAL FILM	SEMI-DIRECTIONAL MEMBRANE	UNDIRECTED MEMBRANE
Tensile Strength	MPA	≥30	≥20	≥10
Elongation At Break	%	≥30	≥60	≥100
Insertion Loss	-	3.0 x 10-4	-	-
Corner Positive Cut Value	-	2.5x10-4	-	-
1MHZ Dielectric Constant	-	1.8-2.2	-	-
Dc breaks Through The Voltage	MV/M	average value 200 low 40	average value 60 low 6	average value 30

Products SpecificationsTel：+86-19803278181

TECHNICAL PARAMETER
PROJECT NAME	UNIT	DESIRED VALUE
PERFORMANCE DENSITY	g/cm3	2.1-2.3
TENSILE STRENGTH	MPA	≥14.0
FAULT STRETCH RATE	%	≥150

$8{S]RI_5RCQW$%9J}%1SF)W$

Hot Tags: ptfe thin film, China ptfe thin film manufacturers, suppliers
